High viscosity VHB double-sided tape Mounting Acrylic Foam Tape

Mode No	Thickness(mm)	Color	Size (cm)	Adhesive Base	Temperature Resistance	Solvent Resistance	Release Force	Tensile Strength	Hold Force	3M Equivalent
WK980-1	0.64	Black	900*33	High Strength Acrylic	≥120°C	High	≥4000	≥7500	＞24hr	4939/5925
WK980-2	0.5	Transparent					≥3500	≥7500		4905
WK980-3	1						≥4000	≥6500		4910
WK980-4	1.5						≥4000	≥6000		4915
WK980-5	2						≥4000	≥5500		4918
WK980-6	0.25	Grey					≥3500	≥8500		4216/5355
WK980-7	0.4						≥3500	≥8500		4215/4926
WK980-8	0.8						≥4000	≥7000		4213/4229
WK980-9	1.2						≥4500	≥6500		4941/4611/4211/5344
WK980-10	1.5						≥4500	≥6000		4956/5356
WK980-11	2						≥4500	≥5500		4620/4991
WK980-12	0.25	White					≥3500	≥8500		4914
WK980-13	0.4						≥4000	≥8000		4920
WK980-14	0.64						≥4000	≥8000		4932/4930/4618
WK980-15	0.8						≥4000	≥7500		4647/4253
WK980-16	1.2						≥4000	≥7000		4945/4950/4951
WK980-17	1.5						≥4000	≥6500		4624
WK980-18	2						≥4000	≥6500		4912/4955
WK980-19	3						≥4000	≥5000		4959/5359

The application of VHB double sided tape in industrial field is very mature. It is not only a kind of “viscose”, but also a structural bonding material. In the industrial scene, VHB double sided tape is often used to replace traditional mechanical connection methods such as screws, rivets and welding, so as to realize lightweight, aesthetic and efficient production.

Automobile manufacturing industry

Body exterior trim assembly

Applications: side skirts, wheel eyebrows, window trims, luggage racks, spoilers (tails), license plate frames, and door bumper strips.

Industrial value: traditional buckles or screws are easy to produce wind noise and vibration when driving at high speed. VHB tape can provide buffer and eliminate noise, and the installation speed is several times faster than drilling.

Window and glass system

Application: windshield decorative strip, skylight frame sealing, rearview mirror base fixing.

Industrial value: It has excellent weather resistance, will not age and fail under exposure and rain, and can bear the difference of thermal expansion coefficient between glass and metal.

Automobile interior trim fixing

Applications: instrument panel assembly, door trim, column trim (A/B/C column), sound insulation cotton, airbag cover.

Industrial value: It can bond different materials (such as ABS plastic and metal), and will not produce volatile compounds (VOCs) like glue, which meets the environmental protection standards in the car.

Batteries and new energy components

Application: fixing the insulation sheet and heat sink of power battery pack, binding and fixing the battery module.

Industrial value: high temperature resistance, flame retardant (specific model), and good cushioning performance, which can protect the battery from road vibration impact.

Electronics and electrical appliance manufacturing industry

Consumer electronics (mobile phone/computer/tablet)

Application:

● Screen assembly: the bonding between the touch screen and the middle frame (black VHB is often used here to prevent light leakage).

● Battery fixing: fix the lithium battery inside the fuselage to prevent shaking.

● Camera module: the fixing of lens and PCB.

● Waterproof and dustproof: as a gasket, it fills the gap of the fuselage.

● Industrial value: ultra-thin thickness (can be as thin as 0.2mm), without occupying internal space; The adhesive strength is high, which can prevent the screen from separating when falling.

White goods

● Application: refrigerator door seal, washing machine control panel, air conditioning air outlet grille, TV frame and backplane connection.

● Industrial value: wide temperature range, can adapt to the low temperature inside the refrigerator and the vibration of the washing machine motor.
